PI small

Position LED indicators 16/24

PI16/24 BASE CODE

Need a quotation? Configure your product then ask us!

Headfirst into your needs.

Get your LED indicator with a round or square head shape, protruding or flush with the panel.

Protruding

Round head

Round display

Head size: Ø24mm Cut-out: Ø16mm

Protruding

Square head

Round display

Head size: 24x24mm Cut-out: Ø16mm

Flush mounting

Round head

Round display

Head size: Ø26,5mm Cut-out: Ø24mm

Flush mounting

Square head

Round display

Head size: 26,5x26,5mm Cut-out: 24x24mm

Ground or disconnector, a full palette at your service.

The DOMO PI series (Position LED indicators) offers a display with a perfectly legible and recognizable illuminated symbol.

The PI SMALL model is available with
• ground or disconnector symbols
• a choice of six colors
• a Bicolor solution (white when turned off, red or green when turned on).

LED cluster light

The presence of 2 LEDs inside spreads an intense and bright colored light evenly diffused.

Pure green

Green LEDs produce a pure green light, enhancing performance and visibility.

IP54

Ingress of dust is not totally prevented, but dust shall not penetrate in a sufficient quantity to interfere with satisfactory operation of the apparatus or to impair safety. Water splashed against the enclosure from any direction shall have no harmful effects. EN 60529

Choose the power supply value that's right for you.*

*And if it's not in the catalogue, try to ask for it.

24

24 V

AC/DC

13÷30V
48

48 V

AC/DC

15÷60V
130

130 V

AC/DC

70÷150V
230

230 V

AC/DC

160÷250V
Or customizable upon request.

Built-in rectifier bridge

Thanks to the built-in rectifier bridge, the device can be powered with both AC or DC power supply without any error.
Backfeed protection

A built-in protection diode absorbs any incidental excess current to avoid reverse feeding, minimizing the risk of LEDs unexpected lighting and hazards to the electrical grid equipment.
Low-voltage glow protection

To avoid the risk of unexpected and random switch-ons, the device will be provided with a Zener diode that properly calibrates the minimum voltage required to switch on the LED Indicator.

Need more informations? Discover all the Technical features.

Easy, fast, connected.

Connecting and disconnecting is as simple as it gets: no complex tools, no second-guessing, just a satisfying click that you can trust every time. Faston connectors lock into place with a reassuring grip, ensuring they stay connected through vibration and motion.

Faston terminals

Do you want to know how to connect it? Find the installation manual and other useful informations in the Library

The secret of all this condensed power:

4 layers PCB

The state of the art of our technological research allows us to insert into this device an SMD equipped with a 4 layers PCB.

Built-in lamp test facility

A built-in circuit provided with specific diodes allows to test the LEDs functionality with no need of external tools for cabling, no extra work, no extra money and no extra space.

is not compatible with
Tropicalization

Enjoy a longer durability: a protective layer covers the whole circuit preventing the potential damages that may occour in dusty, saline, humid and oxidizing environments.
Flying leads

Don’t waste your time with cabling: we can cable wires as long and thick as you need and mount them on the connection terminal you choose.
